How to Build a NAS From Scratch: A Complete Beginner’s Guide

Building a NAS from scratch is simpler than most beginners expect. You need a standard PC with a focus on storage, a compatible operating system, and a clear idea of what you want it to do. This guide walks you through every step — from choosing parts to accessing your first shared folder — so you can build a reliable, cost-effective NAS on your first try.

By the end of this page, you’ll know exactly which hardware to pick, how to assemble it without common mistakes, and how to set up your first share with a backup plan that keeps your data safe.

Step 1: Define Your Use Case Before Buying Anything

Your use case determines every hardware and software choice. A media server for a family of four has very different requirements than a backup target for a small business. Answer these three questions before you spend a cent:

• How much storage do you need now, and in the next 2–3 years? Use our How Much Storage Do You Need for a NAS? guide to estimate.
• What services will the NAS run? Pure file storage, Plex/Jellyfin media streaming, Docker containers, or virtual machines?
• How many users will access it simultaneously? This affects CPU and RAM requirements.

Step 2: Choose CPU, RAM, Case, and PSU Based on Your Use Case

Your hardware choices flow directly from the use case you defined in Step 1. Here’s what each component does in a NAS build:

CPU: The Brains of Your NAS

For a basic file server, an Intel Celeron N5105 or N100 draws only 6–10W idle and supports hardware transcoding for media servers. For heavier workloads like ZFS with compression and multiple VMs, step up to an Intel Core i3-12100 or AMD Ryzen 5 5600G. Read our Best CPU for TrueNAS in 2026 guide for detailed recommendations.

RAM: More Is Better for ZFS

If you plan to use TrueNAS or another ZFS-based OS, aim for at least 8GB as a baseline, with 16GB recommended for 4–6 drives. ZFS caches frequently accessed data in RAM (ARC), so more RAM directly improves performance. Non-ZFS systems like Unraid can run well on 4–8GB for basic file serving.

Case and PSU: Focus on Drive Bays and Efficiency

The case determines how many drives you can install. A Fractal Design Node 304 holds 6 drives in a compact form factor. The SilverStone CS381 holds 8–12 drives for larger builds. For the PSU, choose a 80+ Gold unit rated at 300–450W for a 4–6 drive build. Higher efficiency saves money over time — see our How to Reduce Your NAS’s Power Consumption guide for details.

Step 3: Choose Drives and RAID/ZFS Level

Drive selection and RAID level are the most critical decisions for data safety and usable capacity. Here’s what to consider:

Drive Types: HDD vs SSD

For bulk storage, use 3.5″ mechanical hard drives (HDDs). For a 4-bay NAS, 4TB or 8TB drives offer the best cost-per-TB. Use a small SSD (120–240GB) for the operating system to keep it separate from data drives. If your budget allows, add an SSD cache drive for frequently accessed files.

RAID and Pool Configuration

Here’s how the most common RAID levels work for a 4-drive build:

For a deeper comparison, read our RAID 1 vs RAID 5 guide.

Step 4: Assembly Basics and Common First-Build Mistakes

Assembling a NAS is identical to building a desktop PC, with a few storage-specific considerations. Follow this sequence:

Common Mistakes to Avoid

• Forgetting to install motherboard standoffs — this can short-circuit the board.
• Using mismatched drive sizes in a RAID 5 array — all drives should be the same capacity for optimal performance.
• Skipping the BIOS check — always verify all drives are detected before installing the OS.

Step 5: OS Installation and Initial Configuration

Your choice of operating system determines the feature set and management interface. For beginners, the two most popular options are TrueNAS Scale and Unraid. Read our TrueNAS vs Unraid comparison to decide which fits your needs.

Here’s the general installation process regardless of OS choice:

Step 6: Setting Up Your First Share and a Backup Plan

Once the OS is installed and your pool is created, you need to make storage accessible to your network and protect it with a backup.

Creating Your First Network Share

In TrueNAS, go to “Sharing > Windows Shares (SMB)” and click “Add.” Choose the dataset you created on your pool, give the share a name (e.g., “Media” or “Backups”), and enable “Allow Guest Access” if you want password-free access on your home network. Apply the change, then access it from your PC by typing \\NAS-IP\ShareName in File Explorer.

In Unraid, go to “Shares” and create a new share. Set the “Export” option to “Yes” and choose “Public” or “Secure” access. Apply, and the share appears on your network immediately.

Building a Backup Plan

Your NAS’s RAID protects against drive failure, but a separate backup is essential for ransomware, accidental deletion, or fire/theft. Follow the 3-2-1 rule: three copies of your data, on two different media types, with one copy offsite. For beginners, the simplest approach is:

• Primary copy on your NAS (RAID-protected).
• Secondary copy on an external USB drive connected to the NAS, using rsync or a scheduled snapshot task.
• Tertiary copy in cloud storage (Backblaze B2 or Wasabi) for critical files like family photos and documents.

Bottom Line: Which NAS Build Should You Choose?

For a first-time builder with a family of 2–4 people who need media streaming, file sharing, and photo backup, here’s a clear recommendation:

• CPU: Intel N100 or Celeron N5105 (6–10W idle, supports hardware transcoding).
• RAM: 16GB DDR4 (enough for ZFS ARC and basic Docker containers).
• Case: Fractal Design Node 304 (holds 6 drives, compact).
• Drives: 4 x 8TB HDDs in RAID 10 (16TB usable, good performance and redundancy).
• OS: TrueNAS Scale (free, ZFS-based, great for media and backups).
• Backup: External 8TB USB drive connected to the NAS for weekly backups.

This build costs roughly $600–$800 and provides reliable, expandable storage for years. If your budget is tighter, start with 2 drives in RAID 1 and add more later.
